Oil-Immersed Distribution Transformer
Sealed corrugated-tank distribution transformers from 25 kVA to 2500 kVA, built to IS 1180 loss levels.
Need the datasheet?
Ratings and drawings are issued against the specific make and model you need. Ask and we will email the current datasheet.
Request DatasheetOverview
Our oil-immersed distribution transformers are wound with electrolytic-grade copper or aluminium and assembled in sealed corrugated tanks that need no conservator and lose no oil to breathing. Every unit is routine tested for ratio, vector group, no-load and load losses, insulation resistance and separate-source withstand before dispatch, and is supplied with a full test certificate and rating plate to the ordered specification.
Technical specifications
| Rating | 25 kVA – 2500 kVA |
|---|---|
| Voltage class | 11/0.433 kV, 33/0.433 kV |
| Vector group | Dyn11 (others on request) |
| Cooling | ONAN, sealed corrugated tank |
| Winding | Copper or aluminium, class A insulation |
| Standard | IS 1180 Level 2 / IS 2026 |
Specifications are indicative. Final ratings are confirmed against your site conditions and the approved make.
Applications
- Urban and rural distribution feeders
- Industrial and captive plant substations
- Housing societies, townships and commercial complexes
- Auxiliary supply for solar and infrastructure sites
Interested in the Oil-Immersed Distribution Transformer?
Tell us the rating and quantity you need. We will confirm availability, price and delivery — and quote the installation too if you want it commissioned.
