SF6 Ring Main Unit (RMU)
Sealed-for-life gas-insulated ring main units in 2, 3 and 4-way configurations.
Need the datasheet?
Ratings and drawings are issued against the specific make and model you need. Ask and we will email the current datasheet.
Request DatasheetOverview
Compact ring main units with the switching functions sealed inside a stainless-steel SF6 tank, so performance does not drift with dust, damp or salt in the air. Ring switches and tee-off breakers can be motorised and fitted with an RTU for feeder automation, letting the control room isolate a faulted section without a truck roll. Footprint is small enough for a kiosk or a basement substation.
Technical specifications
| Rated voltage | 11 kV / 22 kV / 33 kV |
|---|---|
| Configuration | 2, 3 and 4 way (CC, CCF, CCV) |
| Ring current | 630 A ring, 200 A tee-off |
| Short-circuit rating | 21 kA for 3 s |
| Insulation | SF6, sealed for life |
| Standard | IEC 62271-200 / IEC 62271-105 |
Specifications are indicative. Final ratings are confirmed against your site conditions and the approved make.
Applications
- Underground HT ring distribution
- Townships, IT parks and campuses
- Metro, airport and hospital networks
- Solar plant feeder switching
