LED Street Light Luminaire
20 W to 250 W IP66 luminaires at up to 150 lm/W, CCMS and smart-control ready.
Need the datasheet?
Ratings and drawings are issued against the specific make and model you need. Ask and we will email the current datasheet.
Request DatasheetOverview
Die-cast aluminium LED street light luminaires with a toughened glass cover, IP66 sealing and a driver compartment that can be opened without disturbing the optics. Surge protection to 10 kV as standard keeps drivers alive on rural feeders, and NEMA sockets allow a controller to be added later for dimming schedules and centralised monitoring.
Technical specifications
| Wattage | 20 W – 250 W |
|---|---|
| Efficacy | 130 – 150 lm/W |
| Colour temperature | 5700 K / 4000 K |
| Driver | Constant current, 10 kV surge protection |
| Ingress & impact | IP66 / IK09 |
| Standard | IS 10322 Part 5 / LM-79 tested |
Specifications are indicative. Final ratings are confirmed against your site conditions and the approved make.
Applications
- Road, highway and junction lighting
- Municipal conventional-to-LED retrofits
- Campus, society and factory road lighting
- Smart-city CCMS controlled networks
Interested in the LED Street Light Luminaire?
Tell us the rating and quantity you need. We will confirm availability, price and delivery — and quote the installation too if you want it commissioned.
